Directional Drilling Rig

Taw qhia

Qhov no Directional Drilling Rig, qauv ZT-100/140, txais yuav digital screen tswj, Cummins diesel cav, Sauer-Danfoss roj twj thiab lwm yam khoom siv txawv teb chaws. Peb tseem tuaj yeem muab koj nrog kev cob qhia kev txhim kho kev cob qhia.

Product details

Specifications

Khoom npe: Directional Drilling Rig

1. Digital Screen Tswj

2. Cummins Diesel Cav 6CTAA8 9-C360 264kw/2200rpm,

3. Max.Spindle torque 38000Nm,

4. spindle ceev 0-54rpm, 0-135rpm.

5. Khib & pinion rub thiab thawb,

6. Max.Pullback (nrog 40T pinion rub) / Thrust quab yuam: 1400kN / 1000kN,

7. Max carrige ceev: 60m / min, Carriage stroke 6900mm,

8. Siv OD114 * 6m laum pas nrig, NC38 xov.

9. Lub kaum sab xis nkag: 10-20 degree .800L/min Mud twj tso kua mis ntawm rig,

10. Max.fluid/siab: 800L/min @ 10Mpa.

11. Main hydraulic Cheebtsam:

12. Sauer-Danfoss roj twj tso kua mis 90L100KP, 90L55KP, ERL100BBS. Danfoss / Sam pistons Hydr-motor SH7V160 H1B1160,

13. Brevini gearbox BL1572,BL1513, Cabin nrog AC, 3.2T Crane.

14. Dimensions: 12050 * 2850 * 3250mm Nyhav: 26T

15. Delivery Dimension: (tshem cov phaj thauj tog rau nkoj thiab crane: 11800 * 2610 * 3250mm, phaj thiab crane muab tso rau hauv lub thawv rods)

16. HS CODE NO.: 8430412900

17. 102 * 6000mm / 114 * 6000mm rods 100pcs thiab lwm yam

Tuam txhab Profile

Drillto tau tsom mus rau trenchless directional drilling teb rau ntau tshaj 20 xyoo, tsis tu ncua kev txhim kho cov neeg siv kev, ua technologies breakthroughs, thiab inspiring los ua ib puas xyoo-laus enterprise nyob rau hauv lub trenchless teb. Drillto tau yeej lub teb chaws high-tech lag luam rau ob lub tuam txhab Shenzhen thiab Wuxi, thiab tau ua tiav lub npe hu ua 'The Leading Enterprises', 'Trenchless Equipment Engineering Technology Research Center', tau qhuas los ntawm "Lav thiab Resources Science thiab Technology First Prize" , tau IS09001, IS014001 zoo thiab ib puag ncig kev tswj dual system ntawv pov thawj, kev tiv thaiv ib puag ncig. CE daim ntawv pov thawj. Lub tuam txhab tau lees paub los ntawm cov koom haum tso cai hauv cov txheej txheem kev lag luam thiab kev tswj kom zoo.

Nws tau tam sim no tau txais yeej 168 technical patents ntawm HDD teb, suav nrog 27 qhov kev tsim patents thiab 141 cov qauv siv hluav taws xob patents, Drillto cov khoom tau lees paub tias yog cov khoom siv high-tech rau ntau zaus. Pab neeg no tau tsom mus rau HDD Fields thiab sib sib zog nqus tau ntau xyoo, thiab lub xub pwg nyom lub luag haujlwm ntawm kev coj HDD kev lag luam rau pem hauv ntej.
