HDD tshuab

ZT-21A
Cov khoom tseem ceeb ntawm lub tshuab hydraulic ntawm lub tshuab HDD no yog tag nrho cov khoom siv los yog sib koom ua ke, nrog lub zog muaj zog thiab txhim khu kev qha. Lub taub hau fais fab yog tsav los ntawm ob lub motors, nrog lub zog loj thiab kev kub ceev. Lub hwj chim lub taub hau yog muab nrog shackle floating ntaus ntawv los tiv thaiv lub laum yeeb nkab xov. Lub tshuab pub mis yog nyob rau hauv daim ntawv ntawm khib thiab pinion tsav, nrog kev ua haujlwm ruaj khov, thiab tau yeej qhov khoom plig zoo heev ntawm Trenchless Association rau ntau zaus. Lub drilling rig muaj cov qauv compact, me me, kev tsim kho siab thiab me me hneev taw.

Khoom Taw qhia

Drillto Trenchless Co., Ltd yog ib qho ntawm feem txhim khu kev qha manufacturers thiab lwm tus neeg ntawm hdd tshuab nyob rau hauv Suav teb, featured los ntawm cov khoom zoo thiab tus nqi zoo. Thov so assured mus yuav hdd tshuab muag ntawm no los ntawm peb lub hoobkas. Tiv tauj peb rau kev pabcuam kev cai.

Ikev taw qhia
Cov khoom tseem ceeb ntawm lub tshuab hydraulic ntawm lub tshuab HDD no yog tag nrho cov khoom siv los yog sib koom ua ke, nrog lub zog muaj zog thiab txhim khu kev qha. Lub taub hau fais fab yog tsav los ntawm ob lub motors, nrog lub zog loj thiab kev kub ceev. Lub hwj chim lub taub hau yog muab nrog shackle floating ntaus ntawv los tiv thaiv lub laum yeeb nkab xov. Lub tshuab pub mis yog nyob rau hauv daim ntawv ntawm khib thiab pinion tsav, nrog kev ua haujlwm ruaj khov, thiab tau yeej qhov khoom plig zoo heev ntawm Trenchless Association rau ntau zaus. Lub drilling rig muaj cov qauv compact, me me, kev tsim kho siab thiab me me hneev taw.

Specifications

1. Cummins cav 6BTA5.9-C150,

2.110kW / 2300rpm, Roj hmab crawler mounted,

3.Rotary torque 6500Nm @ 0-110,0-210 rpm,

4.Rack & Pinion Pullback / thrust: 21T,

5.Triplex Piston twj tso kua mis;

6.Mud ntws tus nqi 240L / min, 8Mpa (1160PSI),

7. Ceramic lub tog raj kheej; Hydraulic clamp rau yeeb nkab pleev / breakout,

8.Max Pushing & rub ceev: 60 m / min.

9.Rack tig lub kaum sab xis: 8--20 degree,

10.Hydraulic twj ltalis CASAPA 100/51/34,

11. Kev sib hloov lub cev muaj zog EATON 6K-310, thiab lwm yam khoom seem

12.60 * 3000mm rods 100 daim.

13. Tshuab Dimension: L * W * H 6200 * 2180 * 2250mm,

14. Tshuab Luj: 7T

15 .HS CODE NO.: 8430412900

Main Technical Parameters

Yam khoom	Hom thiab Qauv
Cav	Cummins cav 6BTA5.9-C150
Pump	Ltalis CASAPA 100 rau kev sib hloov
	Ltalis CASAPA 51 rau thrusting
	Ltalis CASAPA 34 rau kev pab
Lub cev muaj zog	Eaton 6K-390
	Eaton 6K-390
	Qauv: INI 2200
Mud Pump	LeiKe YWB 240/180
Torque	6500N.M,
Kev sib hloov ceev	0-230 RPM
Pullback Force	210 KN
Drill Pipe	Φ60X3000
Lub kaum sab xis	8℃-20 degree
Loj	L * W * H 6200 * 2180 * 2250mm, Luj: 7T
